Intel Core i3-1315U, 16GB DDR5 5600MHz, 500GB M.2 SSD, Micro-Format, No OS

Description

TERRA Ultra compakt PC-Micro with unique silver Design: Space saving and with low power consumption. Powered by 13th Gen. Intel Core i3 Processor and performant M.2- SSD PCIe Storage.

The silver-coloured PC integrates perfectly, both in predominantly dark and in white-designed work environments. Enjoy the advantages of the small form factor. For ergonomic working, we recommend the use of wireless keyboard-mouse combinations. Included: VESA Mounting Kit.

Specifications

Processor
Processor generation	Intel Core i3-13xxx
Processor cache type	Smart Cache
Processor cache	10 MB
Processor model	i3-1315U
Number of processors installed	1
Processor manufacturer	Intel
Processor boost frequency	4.5 GHz
Processor threads	8
Processor cores	6
Processor family	Intel® Core™ i3
Performance cores	2
Efficient cores	4
Processor base power	15 W
Maximum turbo power	55 W
Efficient-core Max Turbo Frequency	3.3 GHz
Performance-core Max Turbo Frequency	4.5 GHz
Memory
Memory layout (slots x size)	2 x 8 GB
Internal memory	16 GB
Maximum internal memory	64 GB
Memory slots	2x SO-DIMM
Internal memory type	DDR5-SDRAM
Memory clock speed	5600 MHz
Storage
Storage media	SSD
Number of storage drives installed	1
Number of storage drives supported	2
RAID support	No
Optical drive type	No
SSD interface	PCI Express
SSD capacity	500 GB
Card reader integrated	Yes
Total storage capacity	500 GB
Storage options	2x M.2 2280 PCIe Gen4x4
SSD form factor	M.2
NVMe	Yes
Graphics
Discrete graphics card	No
Graphics card HDMI ports quantity	1
Graphics card DisplayPorts quantity	1
On-board graphics card family	Intel Iris Xe Graphics
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board graphics card model	Intel Iris Xe Graphics
Resolution description	HDMI 4096x2160 @ 60Hz (4K), Display Port 3840x2160 @ 60Hz (4K)
On-board GPU manufacturer	Intel
Performance
Market positioning	Medical
Product type	PC
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Audio system	High Definition Audio
Optical drive
Optical drive type	No
Network
Ethernet LAN	Yes
Wi-Fi	Yes
Bluetooth	Yes
Bluetooth version	5.2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Ethernet LAN data rates	100,1000 Mbit/s
WLAN controller model	Intel Wi-Fi 6E AX211
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller manufacturer	Intel
LAN controller	Realtek RTL8111H, Dragon RTL8125BG
Ports & interfaces
Combo headphone/mic port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
HDMI version	2.1
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	2
DisplayPorts quantity	1
DC-in jack	Yes
DisplayPort version	1.4
USB Type-C DisplayPort Alternate Mode	Yes
Intel® Thunderbolt 4	Yes
Thunderbolt 4 ports quantity	1
Power
Power supply input frequency	50/60 Hz
Power supply input voltage	100 - 240 V
Power supply	65 W
Power consumption (typical)	15 W
Power consumption (standby)	2.6 W
Power consumption (off)	0.4 W
Power consumption (max)	67 W
Technical details
Cable lock slot type	Kensington
Product type	PC
Trusted Platform Module (TPM)	Yes
Product colour	Black
Chassis type	Micro PC
Audio system	High Definition Audio
Cooling type	Active
Cable lock slot	Yes
Storage options	2x M.2 2280 PCIe Gen4x4
Resolution description	HDMI 4096x2160 @ 60Hz (4K), Display Port 3840x2160 @ 60Hz (4K)
Locale	International repository
Sustainability certificates	ENERGY STAR
Design
Cable lock slot type	Kensington
Product colour	Black
Chassis type	Micro PC
Cooling type	Active
Cable lock slot	Yes
Software
Pre-installed software	1 month trial version for new Microsoft® 365 user
Compatible operating systems	Windows 11 (64-Bit)
Operating system installed	No
Display
Display included	No
Audio
Audio system	High Definition Audio
Operational conditions
Operating relative humidity (H-H)	10 - 75%
Operating temperature (T-T)	5 - 35 °C
Weight & dimensions
Width	130 mm
Depth	140 mm
Height	48.3 mm
Weight	650 g
Packaging content
AC adapter included	Yes
VESA mount included	Yes
Cables included	AC
Manual	Yes
Display included	No
Certificates
Certification	ISO 9001, Assembled in Germany Compatibility: SMBios (DMI), EnergyStar (Valid only for U.S.), EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC
Sustainability
Sustainability certificates	ENERGY STAR
Other features
Trusted Platform Module (TPM)	Yes
On-board graphics card	Yes
Processor manufacturer	Intel
Cooling type	Active
Compatible operating systems	Windows 11 (64-Bit)
Storage options	2x M.2 2280 PCIe Gen4x4
Resolution description	HDMI 4096x2160 @ 60Hz (4K), Display Port 3840x2160 @ 60Hz (4K)
Locale	International repository
Power consumption (off)	0.4 W
