LGA1851, Intel B860, 4 x 288-pin DDR5-5600 max. 192GB, 4x Serial ATA 6G, 2 x M.2 2280, 2 x 2.5G LAN, 500 W

Description

This well-cooled 14-litre barebone PC in cube format houses the performance of Intel's Core Ultra 200 series processors (Socket LGA1851 "Arrow Lake-S") with Integrated Neural Processing Unit (NPU) for demanding AI workloads. It accommodates four large 3.5" hard disks, four RAM moduls, two M.2 SSD cards and a dual-slot graphics card. There are also a wide range of connection options: four UHD-compatible graphics outputs, ten USB ports, two network connections, and five audio ports. Such impressive performance and range of features in an aluminum chassis with a volume of only 14 liters makes SB860R8 the ideal platform for demanding mini-server and workstation PCs with top reliability even under heavy load.

Specifications

Motherboard
Processor socket	LGA 1851 (Socket V1)
Number of processors supported	1
Motherboard chipset	Intel B860
Processor
Built-in processor	No
Processor socket	LGA 1851 (Socket V1)
Number of processors supported	1
Motherboard chipset	Intel B860
Memory
Memory voltage	1.1 V
Memory slots type	DIMM
Number of memory slots	4
Memory channels	Dual-channel
ECC	No
Supported memory types	DDR5-SDRAM
Supported memory clock speeds	5600 MHz
Maximum internal memory	192 GB
Non-ECC	Yes
Internal memory installed	No
Video
On-board graphics card	Yes
Storage
Supported storage drive types	HDD & SSD
Storage drive sizes supported	2.5,M.2
Storage drive interface	Serial ATA III, PCI Express
NVMe	Yes
Storage drives installed	No
M.2 SSD size	2280 (22 x 80 mm)
Graphics
On-board graphics card	Yes
Audio
Built-in speaker(s)	No
Audio chip	RealTek ALC888
Network
Ethernet LAN	Yes
Wi-Fi	No
LAN controller	Intel I226-LM
Ports & interfaces
DisplayPort version	1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	4
HDMI version	2.0b/2.1
DisplayPorts quantity	2
USB 2.0 ports quantity	5
Microphone in	Yes
Headphone outputs	1
HDMI ports quantity	2
Ethernet LAN (RJ-45) ports	2
Design
Product type	PC barebone
Housing material	Aluminium
Cable lock slot type	Kensington
Cable lock slot	Yes
On/off switch	Yes
LED indicators	HDD, Power
Cooling type	Active
Product colour	Black
Chassis type	Cube
Performance
Windows operating systems supported	Windows 11
Linux operating systems supported	Yes
BIOS type	AMI
Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Yes
Processor socket	LGA 1851 (Socket V1)
Number of processors supported	1
Motherboard chipset	Intel B860
Audio chip	RealTek ALC888
Colour
Product colour	Black
Technical details
BIOS type	AMI
Cable lock slot type	Kensington
Cable lock slot	Yes
Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Yes
Quick start guide	Yes
Cooling type	Active
Chassis type	Cube
Sustainability certificates	ErP, ENERGY STAR
Compliance certificates	BSMI, CB, CE, Federal Communications Commission (FCC), RoHS
Packaging data
Power cord included	Yes
Drivers included	Yes
AC adapter included	Yes
Package weight	5 kg
Indication
LED indicators	HDD, Power
Software
Windows operating systems supported	Windows 11
Linux operating systems supported	Yes
Management features
On/off switch	Yes
Sustainability
Sustainability certificates	ErP, ENERGY STAR
Power
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power supply type	Internal power supply unit
Power supply	500 W
Number of power supply units	1
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	215 mm
Depth	332 mm
Height	190 mm
Package weight	5 kg
Weight	3.9 kg
Packaging content
Power cord included	Yes
Drivers included	Yes
AC adapter included	Yes
Quick start guide	Yes
Other features
Chassis type	Cube
