2TB, M.2 PCIe 4.0 x 4, NVMe 1.4, Read: up to 3500 MB/s, Write: up to 2700 MB/s, SmartECC

Key Features

• Built with the latest PCIe 4X4 controller
• 2280 M.2 PCIe Gen4 x 4, NVMe 1.4
• Sequential Read (Max*): Up to 3,500MB/s
• Sequential Write (Max*): Up to 2,700MB/s
• Capacity: 250GB~2000GB
• Thermal Throttling Technology
• End-to-End Datapath Protection
• Operating Temperature: 0 ~ 70°C
• High efficiency slim Graphene heatshield
• SmartECC technology

Description

The P400 Lite is the latest in Patriot’s high-speed Gen 4 x4 PCIe M.2 storage solutions. Featuring low power consumption, multi-application uses and highly compatible M.2 2280 specification for easy installation, the P400 Lite offers excellent reliability for all users. With large storage capacities, faster data access, quick transfer speeds and an improved graphene heatshield for temperature dissipation, the P400 Lite offers sharp performance with zero compromise for quality.

Specifications

Hard drive
PCI Express interface data lanes	x4
SSD capacity	2 TB
Performance
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Interface	PCI Express 4.0
Component for	PC/Laptop
NVMe	Yes
NVMe version	1.4
Sequential write speed (CDM)	2700 MB/s
Sequential read speed (CDM)	3500 MB/s
Sequential read speed (ATTO)	3500 MB/s
Sequential write speed (ATTO)	2700 MB/s
End-to-End Data Protection	Yes
PCI Express interface data lanes	x4
SSD capacity	2 TB
S.M.A.R.T. support	Yes
ECC	Yes
Random write (4KB)	540000 IOPS
Random read (4KB)	380000 IOPS
Data transmission
Random write (4KB)	540000 IOPS
Random read (4KB)	380000 IOPS
Features
Interface	PCI Express 4.0
Component for	PC/Laptop
NVMe	Yes
NVMe version	1.4
Sequential write speed (CDM)	2700 MB/s
Sequential read speed (CDM)	3500 MB/s
Sequential read speed (ATTO)	3500 MB/s
Sequential write speed (ATTO)	2700 MB/s
End-to-End Data Protection	Yes
PCI Express interface data lanes	x4
SSD capacity	2 TB
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
S.M.A.R.T. support	Yes
ECC	Yes
Random write (4KB)	540000 IOPS
Random read (4KB)	380000 IOPS
SSD form factor	M.2
M.2 SSD size	2280 (22 x 80 mm)
Power
Power consumption (average)	2.38 W
Power consumption (idle)	0.38 W
Design
Component for	PC/Laptop
SSD form factor	M.2
Weight & dimensions
Width	220 mm
Weight	9 g
Height	3.8 mm
Depth	80 mm
Package width	130.8 mm
Package depth	6.6 mm
Package height	99.6 mm
Package weight	20 g
Packaging data
Package width	130.8 mm
Package depth	6.6 mm
Package height	99.6 mm
Package weight	20 g
System requirements
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Technical details
Interface	PCI Express 4.0
S.M.A.R.T. support	Yes
Operating temperature (T-T)	0 - 70 °C
ECC	Yes
SSD form factor	M.2
Sustainability compliance	Yes
Warranty period	5 year(s)
Compliance certificates	BSMI, CE, Federal Communications Commission (FCC), RoHS, UKCA
Software
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Sustainability
Sustainability compliance	Yes
Other features
Warranty period	5 year(s)
Compliance certificates	BSMI, CE, Federal Communications Commission (FCC), RoHS, UKCA
