Digitus Firewire 800 (1394b) PCIe Card
£44.19
Skip to product information
SKU: DS-30203-2
Digitus Firewire 800 (1394b) PCIe Card
£44.19
Description
IEEE 1394b PCIexpress Add-On card 3-port, 2x9-Pin Extern+1x9-Pin Intern, XIO2213B
- 3x FireWire 800 (1394b) ports: 2x 9-pin extern + 1x 9-pin intern
- Data transfer rates of 100, 200, 400, and 800Mbps
- Built-in 4-pin power connector, provides extra power when connected to the system power supply (recommended)
IEEE 1394b PCIexpress Add-On card,3-port, 2x9-Pin Extern+1x9-Pin Intern, XIO2213B
Key Features
- 3x FireWire 800 (1394b) ports: 2x 9-pin extern + 1x 9-pin intern
- Chipset: XIO2213B
- Data transfer rates of 100, 200, 400, and 800Mbps
- Built-in 4-pin power connector, provides extra power when connected to the system power supply (recommended)
- Supports hot-swapping and Plug & play connections
- Works with various types of FireWire 800 (1394b) devices, including external hard disk drives, DV camcorders, digital cameras, CD-RW/DVD-ROM drives, and other audio/video devices
- Operating temperature: 0 °C - 70 °C
- Operating humidity: 25% - 65% RH (non-condensing)
- Supports Windows 10, 8, 7, Vista and XP
Description
Extend your system by additional Firewire ports!- 3x FireWire 800 (1394b) ports: 2x 9-pin extern + 1x 9-pin intern
- Data transfer rates of 100, 200, 400, and 800Mbps
- Built-in 4-pin power connector, provides extra power when connected to the system power supply (recommended)
IEEE 1394b PCIexpress Add-On card,3-port, 2x9-Pin Extern+1x9-Pin Intern, XIO2213B
Specifications
| Ports & interfaces | |
|---|---|
| Internal | Yes |
| Host interface | PCIe |
| Connectivity technology | Wired |
| Bandwidth | |
| Maximum data transfer rate | 800 Mbit/s |
| Network | |
| Chipset | XIO2213B |
| Maximum data transfer rate | 800 Mbit/s |
| Technical details | |
| Plug and Play | Yes |
| Hot-swap | Yes |
| Country of origin | China |
| Harmonized System (HS) code | 85176990 |
| Design | |
| Chipset | XIO2213B |
| Plug and Play | Yes |
| Hot-swap | Yes |
| Internal | Yes |
| Country of origin | China |
| Software | |
| Windows operating systems supported | Yes |
| System requirements | |
| Windows operating systems supported | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Operating relative humidity (H-H) | 25 - 65% |
| Packaging data | |
| Low-profile bracket | Yes |
| Manual | Yes |
| Packaging content | |
| Manual | Yes |
| Low-profile bracket | Yes |
| Performance | |
| Plug and Play | Yes |
| Hot-swap | Yes |
| Windows operating systems supported | Yes |
| Other features | |
| Chipset | XIO2213B |
| Manual | Yes |
| Harmonized System (HS) code | 85176990 |
| Country of origin | China |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
