120 mm, 0 - 2000 RPM, 48.8 CFM/ 82.91 m³/h, 1.85 mm/H²O, PWM PST, RGB, 12 V DC, 131 g, Black

Reasons To Buy

RGB FOR FULL COLOURS

The P12 PWM PST RGB 0dB has 12 analogue RGB LEDs in the fan barrel. These can be controlled uniformly and are compatible with the common RGB standards of leading motherboard manufacturers. The fan can thus be fully illuminated directly via the RGB mainboard connection or via an external controller and synchronised with the illumination of other hardware.

0dB MODE - ZERO RPM

The speed of the P12 PWM PST RGB 0dB can be throttled to a standstill via PWM. This allows for silent operation in IDLE and at the same time guarantees maximum performance when needed.

MAXIMUM SMOOTHNESS, MINIMUM VIBRATION

The operating noise of the newly developed ARCTIC motor is barely perceptible even at the lowest speed. In addition, the P12 PWM PST RGB 0dB has rubberised contact surfaces and thus reduces audible vibrations to a minimum.

OPTIMISED FOR HIGH STATIC PRESSURE

The P12 PWM PST RGB 0dB operates with a focused airflow and a high static pressure. The fan thus guarantees extremely efficient cooling, even with increased air resistance, and is therefore suitable for use on heat sinks, radiators and filters.

0 TO 2000 RPM CONTROLLED VIA PWM PST

With a wide speed range and the innovative PWM Sharing Technology (PST), the fan speed of the P12 PWM PST RGB 0dB can be controlled synchronously with all other fans. This reduces noise to a minimum while guaranteeing maximum cooling performance.

HIGH QUALITY PLAIN BEARING

Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. In this way, less heat develops, less bearing noise is generated and the service life of the fan is extended.

Description

Specifications

Performance
Suitable location	Computer case
Fan connector	4-pin + 4-pin
Pulse-width modulation (PWM) support	Yes
Rotational speed (max)	2000 RPM
Noise level	0.3 sone
Bearing type	Fluid Dynamic Bearing (FDB)
Type	Fan
Operating temperature (T-T)	0 - 40 °C
Fan diameter	12 cm
Supported processor sockets	Not supported
Compatible processor series	Not supported
Maximum airflow	48.8 cfm
Minimum air pressure	1.85 mmH2O
Airflow	82.91 m³/h
Number of fans	3 fan(s)
Quantity per pack	3 pc(s)
Design
Fan connector	4-pin + 4-pin
Number of fans	3 fan(s)
Product colour	Black
Cable length	0.4 m
Illumination LED	Yes
Technical details
Type	Fan
Fan diameter	12 cm
Supported processor sockets	Not supported
Compatible processor series	Not supported
Maximum airflow	48.8 cfm
Minimum air pressure	1.85 mmH2O
Airflow	82.91 m³/h
Number of fans	3 fan(s)
Cable length	0.4 m
Fan connector	4-pin + 4-pin
Illumination LED	Yes
Ports & interfaces
Fan connector	4-pin + 4-pin
Power
Starting voltage	5 V
Voltage	12 V
Rated current	0.11 A
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Colour
Product colour	Black
Weight & dimensions
Fan dimensions (W x D x H)	120 x 120 x 25 mm
Package depth	124 mm
Package width	103 mm
Package height	127 mm
Fan weight	131 g
Package weight	644 g
Cable length	0.4 m
Packaging data
Package depth	124 mm
Package width	103 mm
Package height	127 mm
Package weight	644 g
Other features
Harmonized System (HS) code	84733080
Logistics data
Harmonized System (HS) code	84733080
