120 mm, 230 - 1350 RPM, 53 CFM, 90.1 m³/h, 0.3 Sone, PWM, 0.12 A, 12 V DC, Black, 5 Pack

Key Features

• Extremely quiet with low noise impeller
• High airflow and static pressure
• Fluid dynamic bearing ensures extended lifespan
• PWM Plug

Reasons To Buy

Maximum Quietness, Minimum Vibration

Even at low speeds the operating sound of the new ARCTIC motor is barely noticeable. Due to a sinus-magnetizing the new motor only creates about 5 % of the vibration from commutation of a regular DC-motor without filter.

Perfect Case Fan Regulation with PWM

The PWM function allows the motherboard to run the fan precisely at its necessary speed. This guarantees the required cooling and minimizes the noise level.

Long Service Life

The Fluid Dynamic Bearing comes with an oil capsule that avoids lubricant leakage. Thus this bearing is as quiet as a sleeve bearing but comes with a significantly higher service life

Innovative Design Enables Quiet and Efficient Ventilation

The innovative design of the fan blades improves the air flow and facilitates a highly efficient ventilation. The impeller was designed with a focus on minimzing the noise level yet delivering the desired airflow and pressure.

Two Way installation

-Blow warm air out of the case
-Draw cool air into your case

Quality You Can Rely On

To ensure the longevity of our products, we carry out long-term tests under different, sometimes very adverse conditions. In this way, we learn how we can permanently improve our products for our customers. In addition, the excellent results of long-term testing give us the assurance that our products are not only outstanding in terms of quality, but also in terms of durability. This is a certainty that we are happy to pass on to our customers, which is why we give a 6-year manufacturer's guarantee on the F12 PWM.

Description

The F12 PWM case fans are dedicated to outperform their counterparts in terms of cooling performance and noise level.

Specifications

Performance
Suitable location	Computer case
Fan connector	4-pin
Pulse-width modulation (PWM) support	Yes
Rotational speed (min)	230 RPM
Rotational speed (max)	1350 RPM
Noise level	0.3 sone
Bearing type	Fluid Dynamic Bearing (FDB)
Type	Fan
Operating temperature (T-T)	0 - 40 °C
Fan diameter	12 cm
Supported processor sockets	Not supported
Compatible processor series	Not supported
Maximum airflow	53 cfm
Maximum air pressure	1 mmH2O
Airflow	90.1 m³/h
Quantity per pack	5 pc(s)
Design
Fan connector	4-pin
Product colour	Black
Cable length	0.4 m
Technical details
Type	Fan
Fan diameter	12 cm
Supported processor sockets	Not supported
Compatible processor series	Not supported
Maximum airflow	53 cfm
Maximum air pressure	1 mmH2O
Airflow	90.1 m³/h
Cable length	0.4 m
Fan connector	4-pin
Ports & interfaces
Fan connector	4-pin
Power
Starting voltage	5 V
Voltage	12 V
Rated current	0.12 A
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Colour
Product colour	Black
Weight & dimensions
Package depth	130 mm
Package width	127 mm
Package height	123 mm
Width	120 mm
Package weight	725 g
Depth	120 mm
Height	25 mm
Weight	105 g
Cable length	0.4 m
Packaging data
Package depth	130 mm
Package width	127 mm
Package height	123 mm
Package weight	725 g
Package type	Box
Packaging content
Screws included	Yes
Number of screws	20
Package type	Box
Other features
Country of origin	China
