140 mm, 200 - 1950 RPM, PWM, 77.6 CFM, 131.92 m3/h, 12 V DC, 2x 4-pin, 181 g, Red

Key Features

• Optimised for static pressure
• Ideal choice on heatsinks, radiators and (partly-) covered case vents
• Broad RPM range for highest performance and low noise level
• Push- or pull-configuration
• PWM Sharing Technology (PST) regulates fan speed synchronously
• Newly developed, very quiet motor
• Extended life span
• Available in multiple distinct colors

Reasons To Buy

Optimised for Static Pressure

During the development of the new BioniX P140, special emphasis was placed on a focused airstream and thus a high static pressure. The fan guarantees extremely efficient cooling, even with increased air resistance. Therefore, the BioniX P140 is particularly suitable for use on heatsinks and radiators.

Maximum Quietness, Minimum Vibration

Even at low speeds the operating sound of the new ARCTIC motor is barely noticeable.
Due to a sinus-magnetizing the new motor only creates about 5 % of the vibration from commutation of a regular DC-motor without filter. Consequently, there is no need for rubber spacers due to the steady and smooth torque of the new motor.

Extended Life Span

A 10 °C lower motor temperature roughly doubles the life span of a fan. The new ARCTIC motor has a four times longer service life through its low coil temperature. Consequently, we have extended the warranty to 10 years.

200 to 1950 RPM regulated via PWM PST

With a wide range of regulation and the PWM Sharing Technology (PST), the BioniX P140 fan speed can be controlled synchronously with all your other fans together. This keeps noise at a minimum while guaranteeing maximum cooling performance when needed.

High Quality Bearing

Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and
greater efficiency is achieved. As a result, there is less heat development as well as less bearing noise, which means you can enjoy a longer service life from your fan.

Description

BioniX P140
Pressure-optimised 140 mm Gaming Fan with PWM PST

The BioniX P140 fan features completely redesigned fan blades and is optimised for high static pressure. Thus, the BioniX P140 is especially effective when used on heatsinks and with higher air resistance.
The wide RPM range from 200 to 1950 RPM can be regulated seamlessly and synchronously with other fans thanks to ARCTIC's PWM Sharing Technology (PST).
The newly developed motor with a low coil temperature significantly increases the life span of the fan. Therefore we have extended the warranty to 10 years.

Specifications

Performance
Suitable location	Computer case
Fan connector	4-pin + 4-pin
Pulse-width modulation (PWM) support	Yes
Rotational speed (min)	200 RPM
Rotational speed (max)	1950 RPM
Noise level	0.45 sone
Bearing type	Fluid Dynamic Bearing (FDB)
Noise level (high speed)	25.5 dB
Type	Fan
Fan diameter	14 cm
Supported processor sockets	Not supported
Compatible processor series	Not supported
Maximum airflow	77.6 cfm
Airflow	131.92 m³/h
Number of fans	1 fan(s)
Number of fan blades	5
Design
Fan connector	4-pin + 4-pin
Number of fans	1 fan(s)
Product colour	Black, Red
Cable length	0.4 m
Number of fan blades	5
Technical details
Noise level (high speed)	25.5 dB
Type	Fan
Fan diameter	14 cm
Supported processor sockets	Not supported
Compatible processor series	Not supported
Maximum airflow	77.6 cfm
Airflow	131.92 m³/h
Number of fans	1 fan(s)
Cable length	0.4 m
Fan connector	4-pin + 4-pin
Ports & interfaces
Fan connector	4-pin + 4-pin
Power
Voltage	12 V
Power consumption (typical)	1.8 W
Colour
Product colour	Black, Red
Weight & dimensions
Package depth	148 mm
Package width	148 mm
Package height	35 mm
Width	140 mm
Package weight	230 g
Depth	140 mm
Height	28 mm
Weight	181 g
Cable length	0.4 m
Packaging data
Package depth	148 mm
Package width	148 mm
Package height	35 mm
Package weight	230 g
Package type	Box
Packaging content
Screws included	Yes
Number of screws	4
Package type	Box
Other features
Country of origin	China
Harmonized System (HS) code	84733080
Logistics data
Harmonized System (HS) code	84733080
