4K Ultra HD, 3840 x 2160, 60 fps, 21.8K DMIPs, 2 GB RAM, 8 GB eMMC Flash, HDMI 2.1, 10/100/1000 Mbit/s, 2x USB 2.0, S/PDIF, MicoSD, RS-232, Bluetooth 5.2, Dolby Digital, 12 V, 9 W, VESA, Black, 158 x 121 x 38 mm, 500 g

Key Features

• AV1/HEVC 4Kp60 provides high quality images at reduced bandwidth
• Out-of-sight operation using TVI serial interface or IR extender port as standard
• Tamper-proof, ruggedized chassis
• Integrated mounting brackets (VESA) to fit behind a screen for digital signage apps or underneath a desk for hospitality apps
• Power-over-Ethernet for single cable install

Description

High performance 4K UHD enterprise device, optimised to deliver high quality content to digital signage and hospitality applications

The H200 is designed for “out of sight” operation to deliver content across a diverse range of environments – from in-room hospitality through public space signage and advertising applications where demand for 4K-based services is growing rapidly.

Sector-specific features include a Power over Ethernet (PoE) capability for single-cable installation that reduces installation time and cost. A serial display port, IR extender port and VESA mounting all support out-of-sight operation, easy installation, and promote a simplified user experience.

In a rugged case, the device combines a highperformance AV1 and HEVC capability processor with graphics acceleration for fast rendering of high quality graphics. HEVC capability enables the delivery of high quality images in areas where bandwidth or physical head-end storage needs to be optimised.
‍

Specifications

Features
Product colour	Black
Supported radio bands	Not supported
Maximum image resolution	3840 x 2160 pixels
Video formats supported	AV1, AVC, H.264, HEVC/H.265, MPEG2, MPEG4, VP9
Video compression formats	H.264, H.265
Subtitle formats supported	SRT
Audio formats supported	RTSP
Display
Built-in display	No
Storage
Built-in storage media	Yes
Storage media type	Flash
Total storage capacity	8 GB
Compatible memory cards	MicroSD (TransFlash), SD
Card reader integrated	Yes
Video
HD type	4K Ultra HD
Maximum video resolution	3840 x 2160 pixels
Frame rate	60 fps
Supported video modes	720p, 1080p, 2160p
High Dynamic Range (HDR) technology	High Dynamic Range 10+ (HDR10 Plus)
High Dynamic Range (HDR) supported	Yes
Audio
Audio output channels	2.0 channels
Audio decoders	Dolby Digital, Dolby Digital Plus
Ports & interfaces
HDMI ports quantity	1
HDMI version	2.1
Ethernet LAN (RJ-45) ports	1
Audio (L/R) in	1
Audio (L/R) out	1
S/PDIF out port	Yes
USB 2.0 ports quantity	2
RS-232C	Yes
IR input port	Yes
Network
Bluetooth version	5.2
Bluetooth	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN	Yes
Software
Bundled software	Javascript SDK for WebApplication development, REST API for Device Management, Compatible with Orchestrate Cloud Device Management, Pre-integrated CMS solutions, Native Application support
Ergonomics
LED indicators	Power, Stand-by
VESA mounting	Yes
Reset button	Yes
Product colour	Black
Power
AC input voltage	12 V
Power consumption (typical)	9 W
Weight & dimensions
Width	121 mm
Depth	158 mm
Height	38 mm
Weight	500 g
Packaging content
Remote control included	Yes
Cables included	HDMI, S/PDIF, USB
AC adapter included	Yes
IR extender included	Yes
System requirements
Minimum RAM	2000 MB
Minimum processor	21.8K DMIPs
Operational conditions
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	30 - 95%
Design
Product colour	Black
Hard drive
Built-in storage media	Yes
Storage media type	Flash
Total storage capacity	8 GB
File formats
Video formats supported	AV1, AVC, H.264, HEVC/H.265, MPEG2, MPEG4, VP9
Video compression formats	H.264, H.265
Subtitle formats supported	SRT
Audio formats supported	RTSP
Still image
Maximum image resolution	3840 x 2160 pixels
Radio
Supported radio bands	Not supported
Technical details
Product colour	Black
LED indicators	Power, Stand-by
RS-232C	Yes
Compliance certificates	CB, CE, Federal Communications Commission (FCC), RoHS, UKCA
