Intel Core 3 100U, Intel Graphics GPU, 2 x DDR5 SO-DIMM, Intel Wi-Fi 6E AX211, 2.5G LAN, Bluetooth, 5.3, Tall, UK

Key Features

• Performance: Delivers best-in-class performance among comparable mini-PC offerings
• Manageability: Most comprehensive mini-PC with Intel vPro® Enterprise for exceptional security, manageability, and stability
• AI Ready: Harnesses the prowess of Intel® Core™ Ultra processors’ three AI engines for high throughput, low power, and fast response
• Wi-Fi Sensing: Takes advantage of Wi-Fi sensing to deliver instant availability while reducing power consumption
• Wireless Connectivity: Delivers seamless connectivity for certified Bluetooth® dongle-free experiences
• Customizable: Designed for toolless chassis access making upgrades easier, safer, and faster

Description

Compact Power, Intelligent Performance

Smaller, Faster, Better, AI Ready
The ASUS NUC brand represents a commitment to technological excellence, prioritizing innovative product design, to push the boundaries of performance and user experience.

Developed through a partnership between ASUS and Intel, the ASUS NUC product lines anchor on delivering uncompromised performance in the smallest form factors, backed by industry best quality and reliability, innovative modular designs, extended lifes pan options, smart cooling solutions, and advanced AI capabilities. The versatility of the products shines through an array of configurations catering to diverse user needs, from developers, to power users, to casual home use. Positioned as the preferred choice for a variety of business applications, vertical industries, and everyday users, the ASUS NUC combines exceptional performance with essential features, aiming to shape the next generation of PC experiences.

With a focus on supporting diverse businesses and enhancing PC applications, the ASUS NUC aspires to deliver on the brand promise of delivering the Next Unit of Compute (NUC) and make a lasting impact in the ever-evolving tech landscape.

Toolless Design
ASUS NUC 14 Pro offers toolless access to make it easy to open up the chassis to assess the M.2 PCIe SSD module for easy upgrades.

Certified Bluetooth
dongle-free experience
A certified Bluetooth dongle offers hassle-free operation, cost savings, and resolves ITDM issues. It eliminates concerns such as lost dongles, PC Bluetooth compatibility, and USB port limitations on NUC.

The dongle-free approach simplifies pairing, enhances audio quality, and improves control in video collaboration calls.

Specifications

Motherboard
Number of processors supported	1
Processor
Thermal Design Power (TDP)	15 W
Built-in processor	Yes
Processor model	100U
Processor threads	8
Processor cores	6
Processor family	Intel Core 3
Number of processors supported	1
Processor manufacturer	Intel
Processor cache	10 MB
Performance cores	2
Efficient cores	4
Performance-core boost frequency	4.7 GHz
Efficient-core boost frequency	3.3 GHz
Processor generation	Intel Core (Series 1)
Memory
Memory slots type	SO-DIMM
Number of memory slots	2
Memory channels	Dual-channel
Supported memory types	DDR5-SDRAM
Supported memory clock speeds	5600 MHz
Maximum internal memory	96 GB
Video
On-board graphics card	Yes
Graphics card family	Intel
Storage
Supported storage drive types	SSD
Storage drive sizes supported	2.5,M.2
Storage drive interface	PCI Express, Serial ATA III
NVMe	Yes
Graphics
On-board graphics card	Yes
Graphics card family	Intel
On-board graphics card model	Intel Graphics
Audio
Built-in speaker(s)	No
Network
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Bluetooth version	5.3
Bluetooth	Yes
Ethernet LAN	Yes
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX211
Ports & interfaces
DC-in jack	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
HDMI version	2.1
VGA (D-Sub) ports quantity	0
USB 2.0 ports quantity	1
HDMI ports quantity	2
Ethernet LAN (RJ-45) ports	1
Thunderbolt 4 ports quantity	2
USB4 Gen 2x2 ports quantity	1
Design
VESA mounting	Yes
Product type	Mini PC barebone
Cable lock slot type	Kensington
Cable lock slot	Yes
Cooling type	Active
Product colour	Black
Chassis type	UCFF
Performance
Windows operating systems supported	Windows 11
Number of processors supported	1
Colour
Product colour	Black
Technical details
Cable lock slot type	Kensington
Cable lock slot	Yes
Quick start guide	Yes
Processor cores	6
Cooling type	Active
Chassis type	UCFF
Packaging data
Power cord included	Yes
Software
Windows operating systems supported	Windows 11
Power
Power supply type	External AC adapter
Power supply	90 W
Weight & dimensions
Width	144 mm
Depth	112 mm
Height	41 mm
Weight	570 g
Packaging content
Power cord included	Yes
Quick start guide	Yes
Other features
Chassis type	UCFF
