NUC 12 Pro Kit, Intel Core i3 1220P, Up to 64 GB dual-channel DDR4-3200 SODIMMs

Key Features

• 12th Gen Intel® Core™ i7/i5/i3 processors or Intel vPro® Enterprise with 12th Gen Intel® Core™ i7/i5 processors
• Intel® Iris® Xe graphics
• Up to 64 GB dual-channel DDR4-3200 SODIMMs
• M.2 22x80 key M slot for PCIe x4 Gen 4 NVMe SSD
• M.2 22x42 key B slot for PCIe x1 Gen 3, USB 3.2 Gen 2, USB 2.0, and SATA SSD expandability
• Support in tall chassis for third SSD with 2.5” drive capability (up to 15mm tall)

Description

Smaller, Faster, Better, AI Ready
The ASUS NUC brand represents a commitment to technological excellence, prioritizing innovative product design, to push the boundaries of performance and user experience.
Developed through a partnership between ASUS and Intel, the ASUS NUC product lines anchor on delivering uncompromised performance in the smallest form factors, backed by industry best quality and reliability, innovative modular designs, extended lifespan options, smart cooling solutions, and advanced AI capabilities. The versatility of the products shines through an array of configurations catering to diverse user needs, from developers, to power users, to casual home use. Positioned as the preferred choice for a variety of business applications, vertical industries, and everyday users, the ASUS NUC combines exceptional performance with essential features, aiming to shape the next generation of PC experiences.
With a focus on supporting diverse businesses and enhancing PC applications, the ASUS NUC aspires to deliver on the brand promise of delivering the Next Unit of Compute (NUC) and make a lasting impact in the ever-evolving tech landscape.

Specifications

Processor
Built-in processor	Yes
Processor model	i3-1220P
Processor boost frequency	4.4 GHz
Processor threads	12
Processor cores	10
Processor family	Intel® Core™ i3
Processor manufacturer	Intel
ECC supported by processor	No
Processor cache	12 MB
Performance cores	2
Efficient cores	8
Performance-core Max Turbo Frequency	4.4 GHz
Efficient-core Max Turbo Frequency	3.3 GHz
Processor generation	12th gen Intel® Core™ i3
Memory
Memory slots type	SO-DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	3200 MHz
Maximum internal memory	64 GB
Video
On-board graphics card	Yes
Graphics card family	Intel
Storage
Supported storage drive types	SSD
Storage drive sizes supported	M.2
SSD form factor	M.2
NVMe	Yes
Graphics
On-board graphics card	Yes
Graphics card family	Intel
On-board graphics card model	Intel® UHD Graphics
Audio
Audio output channels	2.0 channels
Built-in speaker(s)	No
Audio chip	Realtek ALC269
Network
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Bluetooth version	5.2
Bluetooth	Yes
Ethernet LAN	Yes
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX211
Ports & interfaces
Serial port via internal header	No
Combo headphone/mic port	Yes
DC-in jack	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
HDMI version	2.1
VGA (D-Sub) ports quantity	0
USB 2.0 ports quantity	1
HDMI ports quantity	2
Ethernet LAN (RJ-45) ports	1
Thunderbolt 4 ports quantity	2
Design
Product type	Mini PC barebone
On/off switch	Yes
Cooling type	Active
Product colour	Black
Performance
Audio output channels	2.0 channels
Audio chip	Realtek ALC269
Colour
Product colour	Black
Technical details
Processor cores	10
Cooling type	Active
Management features
On/off switch	Yes
Power
Power supply type	External AC adapter
Weight & dimensions
Width	117 mm
Depth	112 mm
Height	54 mm
Weight	750 g
