Description
Intel Core i5-1235U, 2 x SO-DIMM DDR4-3200 max. 64GB, 1 x 2.5" SATA, 2 x M.2 NVMe (RAID support), Gigabit Ethernet, 65W
Description
The NC40U series comes with powerful and efficient 12th generation Intel Core processors, codenamed "Alder Lake-U". Despite the nano format with only 850 ml volume, it offers enormous connection variety and expansion options. Thus, up to three UHD displays (4K/60Hz) and up to seven USB 3.2 devices can be connected, and two NVMe/SSD cards in M.2-2280 format as well as one 2.5" hard drive (up to 15 mm thickness) can be installed. The NC40U series is ideal for Digital Signage, POS, control, office or even multimedia.Specifications
| Motherboard | |
|---|---|
| Number of processors supported | 1 |
| Motherboard chipset | Intel SoC |
| Processor | |
| Built-in processor | Yes |
| Processor model | i5-1235U |
| Processor threads | 12 |
| Processor cores | 10 |
| Processor family | Intel® Core™ i5 |
| Number of processors supported | 1 |
| Motherboard chipset | Intel SoC |
| Processor manufacturer | Intel |
| CPU configuration (max) | 1 |
| Processor cache | 12 MB |
| Performance cores | 2 |
| Efficient cores | 8 |
| Processor generation | 12th gen Intel® Core™ i5 |
| Memory | |
| Memory voltage | 1.2 V |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Memory channels | Dual-channel |
| ECC | No |
| Supported memory types | DDR4-SDRAM |
| Supported memory clock speeds | 3200 MHz |
| Maximum internal memory | 64 GB |
| Non-ECC | Yes |
| Video | |
| On-board graphics card | Yes |
| Graphics card family | Intel |
| Storage | |
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5,M.2 |
| Storage drive interface | PCI Express, Serial ATA III |
| Number of storage drives supported | 3 |
| Card reader integrated | No |
| NVMe | Yes |
| Graphics | |
| Maximum resolution | 7680 x 4320 pixels |
| On-board graphics card | Yes |
| Graphics card family | Intel |
| On-board graphics card model | Intel® UHD Graphics |
| Audio | |
| Built-in speaker(s) | No |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| LAN controller | Intel® I219 |
| Ports & interfaces | |
| DisplayPort version | 1.4a |
| DC-in jack | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI version | 2.0b |
| DisplayPorts quantity | 1 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Expansion slots | |
| PCI Express slots version | 3.0, 4.0 |
| Number of M.2 (M) slots | 2 |
| Design | |
| VESA mounting | Yes |
| Product type | Mini PC barebone |
| Housing material | Plastic |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| On/off switch | Yes |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| Safety | CB IEC60950/62368, cTUVus (UL 62368) |
| LED indicators | HDD, Power |
| Cooling type | Active |
| Product colour | Black |
| Chassis type | 0.84L sized PC |
| Performance | |
| Maximum resolution | 7680 x 4320 pixels |
| Windows operating systems supported | Windows 10, Windows 11 |
| Linux operating systems supported | Yes |
| BIOS type | AMI |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Operating system installed | No |
| Number of processors supported | 1 |
| Motherboard chipset | Intel SoC |
| Harmonized System (HS) code | 84733080 |
| Colour | |
| Product colour | Black |
| Technical details | |
| BIOS type | AMI |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Quick start guide | Yes |
| Processor cores | 10 |
| Cooling type | Active |
| Chassis type | 0.84L sized PC |
| Sustainability compliance | Yes |
| Sustainability certificates | ENERGY STAR, ErP |
| Compliance certificates | BSMI, CE, Federal Communications Commission (FCC), RoHS, UKCA |
| Packaging data | |
| Power cord included | Yes |
| Drivers included | Yes |
| AC adapter included | Yes |
| Package weight | 1.2 kg |
| Indication | |
| LED indicators | HDD, Power |
| Software | |
| Windows operating systems supported | Windows 10, Windows 11 |
| Linux operating systems supported | Yes |
| Operating system installed | No |
| Management features | |
| On/off switch | Yes |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Sustainability | |
| Sustainability compliance | Yes |
| Sustainability certificates | ENERGY STAR, ErP |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| AC adapter output voltage | 19 V |
| AC adapter output current | 3.42 A |
| Power supply type | External AC adapter |
| Power supply | 65 W |
| Number of power supply units | 1 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Certificates | |
| Safety | CB IEC60950/62368, cTUVus (UL 62368) |
| Weight & dimensions | |
| Width | 142 mm |
| Depth | 142 mm |
| Height | 42 mm |
| Package weight | 1.2 kg |
| Weight | 400 g |
| Packaging content | |
| Power cord included | Yes |
| Drivers included | Yes |
| AC adapter included | Yes |
| Quick start guide | Yes |
| Other features | |
| Chassis type | 0.84L sized PC |
