27", WQHD IPS 2560 x 1440 px, 350 cd/m², AdobeRGB, sRGB, ColorNavigator, HDMI, DVI, DP, USB Type-C, 36 kWh/1000h, G

Key Features

• 27-inch wide gamut LCD with 2560 x 1440 pixels (WQHD) to deliver ultra-sharp details
• EIZO microchip ensures precise, consistent and lasting colour display
• Wide gamut covering 99% of the Adobe RGB colour gamut
• Precise hardware calibration of brightness, white balance and gamma
• Digital Uniformity Equaliser for top-rate luminance distribution and colour purity
• Colour precision ensured via 16-bit look-up-table and up to 10-bit colour reproduction
• USB-C (DisplayPort signal channel and power supply up to 60 W), DisplayPort, DVI-D and HDMI ports
• USB hub with two USB 3.1 and two USB 2.0 downstream ports
• ColorNavigator calibration software available for free download
• Recommended optional accessories: measuring device for hardware calibration and monitor hood

Reasons To Buy

Outstandingly sharp image quality

The monitor has an impressive top resolution (2560 x 1440), a very good contrast ratio of 1000:1 and a brightness of 350 cd/m². For example, you can edit graphics and images down to the pixel. As an added benefit, text contours are clear and precise. The LCD panel with the IPS (Wide Gamut) panel allows for a viewing angle of 178 degrees. Ensuring that hue and contrast remain stable for the viewer.

Wide gamut color space

To be able to use the entire colour spectrum of modern cameras, you need a monitor with the largest possible colour space. Only then is it possible to visually assess and edit the saturated hues contained in the file. That is why the IPS panel of the ColorEdge CS2731 covers, for example, the wide AdobeRGB photo gamut as well as the CMYK print gamut ISO-Coated V2 to more than 99 %. This means that the full colour spectrum of modern cameras is represented unaltered and without gaps. And a precise simulation of the print result in the softproof view is also guaranteed.

Perfect settings right from the factory

Every ColorEdge CS2731 is individually measured and optimally configured in the factory, enabling it to be used immediately after it has been unboxed. To this end, the gamma curves for the red, green and blue channels are closely checked and corrected, if necessary. This unique EIZO factory calibration enables the user to start using the monitor with the preset gamut range right out of the box. This painstaking calibration at the factory ensures that the user can quickly recalibrate the monitor if needed using ColorNavigator.

Hardware calibration without any compromises

It is essential that the monitor is regularly calibrated to ensure that it always displays the same file in the same way over its entire service life. To do so, all ColorEdge monitors employ lossless hardware calibration. Unlike software calibration, which always involves the risk of loss of display quality, hardware calibration not only creates an adjustment profile for the graphics board but also calibrates the monitor’s LUT (look-up-table).

EIZO software for fast calibration and printing

Each monitor ages and changes its display properties. This is why graphics monitors, which require an absolutely constant image display over the entire service life, must be regularly calibrated and adjusted. With the free calibration software ColorNavigator 7 from EIZO, the ColorEdge CS2731 can be adjusted within 90 seconds (measured with a MacBook Pro and EX4), easily and without any losses. This is to ensure that the same image still looks the same on the monitor five years from now.

EIZO microchip

The CS2731 has a high-quality microchip (ASIC, Application-Specific Integrated Circuit), which EIZO developed especially for the special requirements involved in work demanding high colour accuracy. This microchip is the brain of a ColorEdge as it guarantees the precise, uniform and constant image display that is the hallmark of EIZO.

Cutting-edge connectivity with USB-C

Image signal, USB data transfer as well as power supply with up to 60 W, all this and more can be realised with a single USB-C cable. This makes the ColorEdge CS2731 the central dock of the graphic workflow. Peripheral devices such as a mouse, keyboard or printer can be connected directly to the USB-A ports. Mobile devices such as laptops or tablets can even be charged via the USB-C cable with up to 60 W via the USB-C cable. In this way, a laptop and CS2731 can be turned into a fully-fledged desktop workstation with a quick flick of the wrist.

One monitor, many ports

The CS2731 supports a wide range of video formats via USB-C, HDMI and DisplayPort interfaces. This means that the monitor can not only be integrated into PC-based workflows but can also be used with HDMI feeders.

KVM switch

It's never been easier to operate different PCs with a single mouse and keyboard. With its USB upstream ports, the CS2731 has a built-in KVM (Keyboard Video Mouse) switch. The monitor automatically links the mouse and keyboard to the currently active source computer. This means, for example, that a desktop PC and a laptop or a work and home PC can be operated on the same combination of monitor, mouse and keyboard. This ensures uninterrupted work and a tidy workspace.

Anti-glare coating: more image, less reflection

The CS2731 offers a perfect, non-glare surface. By minimising glare by diffusing the reflected light, the CS2731 effectively protects your eyes from straining. This keeps your eyes from getting as tired and allows you to sit comfortably in front of the monitor, without having to sit in a forced position to prevent glare.

Socially responsible production

The CS2731 is produced in a socially responsible way. It is free of child labour and forced labour. Suppliers along the supply chain have been carefully selected and they have also committed themselves to produce in a socially responsible way. This applies in particular to conflict minerals. We present a detailed report about our social responsibility annually and voluntarily.

Environmentally and climate friendly

Each CS2731 is manufactured in our own factory, which implements an environmental management system in accordance with ISO 14001. This includes measures to reduce waste, wastewater and emissions, resource and energy consumption, as well as to encourage environmentally conscious behaviour among employees. We publicly report on these measures on an annual basis.

Sustainable and durable

The CS2731 is designed for a long service life that takes into account the entire lifecycle and impact on the environment. It is generally well above the five-year guarantee. Spare parts are available up to five years after the end of production. The monitor’s long service life and the ability to repair it save resources and the climate. When designing the CS2731 we paid attention to reducing resource consumption by using high-quality components and materials and being meticulous in production.

Five-year warranty

EIZO grants a five-year warranty. This is possible thanks to the highly developed production process based on a simple principle of success: sophisticated and innovative technology, made from high-end materials.

Description

The CS2731 unites precision, colour fidelity and cutting-edge connectivity thanks to its USB-C port. This makes the monitor the central interface for the graphic workflow of sophisticated creatives with high standards. The wide gamut, 16-bit look-up-table and precise factory calibration of the CS2731 allows you to enjoy an unadulterated look at your image files in creative workflows requiring high colour accuracy. Convenient functionalities such as monitor signal transmission, rapid data transfer and the power supply feature for connected devices are enabled with just one USB-C port.

Specifications

Display
HDCP	Yes
Display brightness (typical)	350 cd/m²
Screen shape	Flat
Display number of colours	1.073 billion colours
Native aspect ratio	16:9
DDC/CI	Yes
Maximum refresh rate	60 Hz
sRGB coverage (typical)	100%
Adobe RGB coverage	99%
HD type	Quad HD
Display technology	LED
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Pixel pitch	0.233 x 0.233 mm
Viewable size, horizontal	59.7 cm
Viewable size, vertical	33.6 cm
Digital horizontal frequency	15 - 89 kHz
Digital vertical frequency	23 - 61 Hz
Separate H/V sync	Yes
Supported graphics resolutions	2560 x 1440
Display resolution	2560 x 1440 pixels
Response time	16 ms
Display diagonal	68.6 cm (27")
Contrast ratio (typical)	1000:1
Touchscreen	No
Panel type	IPS
DCI-P3 coverage	95%
Hardware calibration	Yes
Colour gamut standard	Adobe RGB
Performance
Built-in camera	No
AMD FreeSync	No
NVIDIA G-SYNC	No
Low Blue Light technology	Yes
Flicker-free technology	Yes
Management features
On Screen Display (OSD)	Yes
Multimedia
Built-in camera	No
TV tuner integrated	No
Design
Market positioning	Graphics design
Certification	CE, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241- 307), cTÜVus, TÜV/S, EAC, PSE, FCC-B, CAN ICES-3 (B), RCM, VCCI-B, CCC, RoHS, China RoHS, WEEE
Product colour	Black
Camera
Built-in camera	No
Ports & interfaces
Built-in USB hub	Yes
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports	2
USB Type-A downstream ports quantity	4
DVI port	Yes
VGA (D-Sub) ports quantity	0
DVI-D ports quantity	1
HDMI ports quantity	1
DisplayPorts quantity	1
HDCP	Yes
HDMI	Yes
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	60 W
USB Type-C DisplayPort Alternate Mode	Yes
TV tuner
TV tuner integrated	No
Technical details
Cable lock slot	Yes
On/off switch	Yes
HDMI	Yes
Product colour	Black
Sustainability certificates	ENERGY STAR
Compliance certificates	RoHS
Weight (with stand)	10.1 kg
Touchscreen	No
Ergonomics
VESA mounting	Yes
Cable lock slot	Yes
Panel mounting interface	100 x 100 mm
Swivelling	Yes
Swivel angle range	0 - 344°
Tilt angle range	-5 - 35°
Pivot	Yes
On Screen Display (OSD)	Yes
Pivot angle	-90 - 90°
Height adjustment	Yes
Cable lock slot type	Kensington
Tilt adjustment	Yes
Adjustable height (max)	15.5 cm
On/off switch	Yes
Power
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	159 W
Power consumption (standby)	0.5 W
Power consumption (typical)	35.7 W
Energy efficiency scale	A to G
Energy efficiency class (SDR)	G
Energy consumption (SDR) per 1000 hours	36 kWh
European Product Registry for Energy Labelling (EPREL) code	356550
Weight & dimensions
Width (with stand)	638 mm
Depth (with stand)	265 mm
Height (with stand)	404.1 mm
Weight (with stand)	10.1 kg
Weight (without stand)	6.5 kg
Packaging content
Quick start guide	Yes
Cables included	AC, HDMI, USB Type-C
Sustainability
European Product Registry for Energy Labelling (EPREL) code	356550
Sustainability certificates	ENERGY STAR
Packaging data
Quick start guide	Yes
Cables included	AC, HDMI, USB Type-C
Other features
On/off switch	Yes
Certification	CE, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241- 307), cTÜVus, TÜV/S, EAC, PSE, FCC-B, CAN ICES-3 (B), RCM, VCCI-B, CCC, RoHS, China RoHS, WEEE
TV tuner integrated	No
DCI-P3 coverage	95%
Hardware calibration	Yes
Compliance certificates	RoHS
Power consumption (max)	159 W
Quick start guide	Yes
HDMI	Yes
USB Power Delivery up to	60 W
Energy efficiency scale	A to G
USB Type-C DisplayPort Alternate Mode	Yes
Touchscreen	No
USB Power Delivery (USB PD)	Yes
Certificates
Certification	CE, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241- 307), cTÜVus, TÜV/S, EAC, PSE, FCC-B, CAN ICES-3 (B), RCM, VCCI-B, CCC, RoHS, China RoHS, WEEE
Logistics data
Harmonized System (HS) code	85285210
