Neomounts WL70-450BL11 Monitor/TV mount wall - 17-32" - 2-9 kg - VESA 75x75-100x100 - d 9-54 cm - gas spring - full motion - black

Description

The Neomounts WL70-450BL11 is a full motion wall mount for flat screens up to 32" with a maximum weight capacity of 9 kg. The versatile tilt (135°), rotate (360°) and swivel (180°) technology allows you to create the optimum viewing angle.

The WL70-450BL11 has a depth of 9-54 cm and is suitable for screens that meet VESA hole pattern 75x75 to 100x100 mm.

The mount can be easily adjusted in height using the gas spring. The cable management system allows you to route and secure any loose cables at the back of the screen. Additionally, the mount features an Easy-release VESA, that allows you to attach the TV in a wink of an eye.

Specifications

Mounting
Maximum weight capacity (per display)	9 kg
Mounting type	Wall
Minimum screen size	43.2 cm (17")
Panel mounting interface	75 x 75 mm
Number of displays supported	1
Minimum VESA mount	75 x 75 mm
Maximum VESA mount	100 x 100 mm
Maximum screen size	81.3 cm (32")
Maximum weight capacity	9 kg
Ergonomics
Height adjustment	Yes
Height adjustment range	0 - 250 mm
Cable management	Yes
Tilt angle range	-45 - 90°
Swivel angle range	0 - 180°
Swivel angle	180°
Angle of rotation	360°
Distance to the wall (min)	9 cm
Distance to the wall (max)	54 cm
Height adjustment type	Gas spring
Rotating	Yes
Tilt adjustment	Yes
Swivelling	Yes
Technical details
Cable management	Yes
Angle of rotation	360°
Number of displays supported	1
Distance to the wall (min)	9 cm
Distance to the wall (max)	54 cm
Product colour	Black
Mounting type	Wall
Country of origin	China
Package net weight	2.3 kg
Master (outer) case net weight	1.6 kg
Quantity per pack	1 pc(s)
Design
Cable management	Yes
Product colour	Black
Housing material	Steel
Weight & dimensions
Width	117 mm
Depth	475 mm
Height	491 mm
Weight	1.64 kg
Depth (max)	47.5 cm
Packaging data
Package width	305 mm
Package depth	405 mm
Package height	90 mm
Package weight	2.3 kg
Logistics data
Master (outer) case width	305 mm
Master (outer) case length	405 mm
Master (outer) case height	90 mm
Master (outer) case gross weight	2.3 kg
Products per master (outer) case	1 pc(s)
Master (outer) case net weight	1.6 kg
Products per pallet (EU)	90 pc(s)
Harmonized System (HS) code	7326909890
Other features
Mounting type	Wall
Mounting	Screws
Minimum weight	2 kg
Country of origin	China
