23.8", IPS FHD 1920 x 1080 px, 250 cd/m², 5 ms, 1000:1, HDMI, VGA, DP, USB, 9 kWh/1000h, B

Key Features

• 23.8-inch LCD monitor in 16:9 aspect ratio featuring IPS technology for excellent image quality
• Bezel only 1 mm: amazingly compact and ultra-elegant design
• Flicker-free image reproduction thanks to hybrid brightness control
• Auto EcoView and EcoView Optimizer for maximum energy-efficiency and superb ergonomics
• Optimised antireflection properties and flexible positioning
• USB 3.1 hub with one upstream and four downstream ports
• DisplayPort, HDMI, DVI-D and D-Sub signal inputs
• Proven to be environmentally friendly and produced in a socially responsible way

Description

Energy-saving, ergonomic, reliable: the EV2460 offers a wide range of connection options thanks to DisplayPort, HDMI, DVI-D and D-Sub signal inputs as well as four USB downstream ports. The EV2460 caters for sophisticated computer workstations with the highest demands. Image quality and ergonomics are equally convincing. With a resolution of 1920 x 1080 pixels, an IPS LCD panel with an antireflective surface, this display excels at detailed, crystal-clear image reproduction.

Specifications

Display
HDCP	Yes
Display brightness (typical)	250 cd/m²
Screen shape	Flat
Display number of colours	16.78 million colours
Native aspect ratio	16:9
Pixel density	93 ppi
Maximum refresh rate	60 Hz
HD type	Full HD
Display technology	LCD
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Pixel pitch	0.2745 x 0.2745 mm
Horizontal scan range	31 - 68 kHz
Vertical scan range	59 - 61 Hz
Viewable size, horizontal	52.7 cm
Viewable size, vertical	29.6 cm
Digital horizontal frequency	31 - 68 kHz
Digital vertical frequency	51 - 59 Hz
Supported graphics resolutions	1920 x 1080 (HD 1080)
Backlight type	W-LED
Display resolution	1920 x 1080 pixels
Response time	5 ms
Display diagonal	60.5 cm (23.8")
Contrast ratio (typical)	1000:1
Touchscreen	No
Panel type	IPS
LED backlight	Yes
Colour gamut standard	sRGB
Anti-glare screen	Yes
Audio
Built-in speaker(s)	Yes
RMS rated power	2 W
Performance
Built-in speaker(s)	Yes
RMS rated power	2 W
Built-in camera	No
AMD FreeSync	No
NVIDIA G-SYNC	No
Low Blue Light technology	Yes
Flicker-free technology	Yes
Management features
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Swedish
Multimedia
Number of speakers	2
Built-in speaker(s)	Yes
RMS rated power	2 W
Built-in camera	No
Design
Market positioning	Office
Feet colour	Black
Certification	CE, UKCA, CB, C-Tick, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 9, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC
Product colour	Black
Camera
Built-in camera	No
Ports & interfaces
Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-B
Number of upstream ports	1
USB Type-A downstream ports quantity	4
Headphone out	Yes
DVI port	Yes
VGA (D-Sub) ports quantity	1
DVI-D ports quantity	1
HDMI ports quantity	1
DisplayPorts quantity	1
HDCP	Yes
Headphone outputs	1
Headphone connectivity	3.5 mm
HDMI	Yes
Number of USB Type-B upstream ports quantity	1
Technical details
Height (without stand)	350.4 mm
Depth (without stand)	53.6 mm
Width (without stand)	537.8 mm
Feet colour	Black
Cable lock slot	Yes
HDMI	Yes
Product colour	Black
Sustainability compliance	Yes
Sustainability certificates	ENERGY STAR, EPEAT Climate +, EPEAT Silver, TCO
Warranty period	5 year(s)
Compliance certificates	C-TICK, CB, CCC, CE, China RoHS, Federal Communications Commission (FCC), ICES, PSE, RCM, RoHS, cTUVus, UKCA, VCCI, WEEE
Weight (with stand)	5.9 kg
Touchscreen	No
Ergonomics
VESA mounting	Yes
Cable lock slot	Yes
Panel mounting interface	100 x 100 mm
Swivelling	Yes
Swivel angle range	0 - 344°
Tilt angle range	-5 - 35°
Pivot	Yes
On Screen Display (OSD)	Yes
Pivot angle	-90 - 90°
On Screen Display (OSD) languages	Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Swedish
Height adjustment	Yes
Cable lock slot type	Kensington
Tilt adjustment	Yes
Adjustable height (max)	14 cm
Power
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	50 W
Power consumption (standby)	0.5 W
Power consumption (typical)	9 W
Energy efficiency scale	A to G
Energy efficiency class (SDR)	B
Energy consumption (SDR) per 1000 hours	9 kWh
European Product Registry for Energy Labelling (EPREL) code	346699
Operational conditions
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	10 - 90%
Weight & dimensions
Height (without stand)	350.4 mm
Depth (without stand)	53.6 mm
Width (without stand)	537.8 mm
Width (with stand)	537.8 mm
Depth (with stand)	233 mm
Height (with stand)	333.6 mm
Weight (with stand)	5.9 kg
Weight (without stand)	3.8 kg
Packaging content
Stand included	Yes
Quick start guide	Yes
Cables included	AC, DisplayPort, USB Type-A to USB Type-B
Sustainability
European Product Registry for Energy Labelling (EPREL) code	346699
Sustainability compliance	Yes
Sustainability certificates	ENERGY STAR, EPEAT Climate +, EPEAT Silver, TCO
Packaging data
Stand included	Yes
Quick start guide	Yes
Cables included	AC, DisplayPort, USB Type-A to USB Type-B
Other features
Certification	CE, UKCA, CB, C-Tick, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 9, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC
Automatic brightness control	Yes
Warranty period	5 year(s)
Look-up table (LUT) bit depth	10
Compliance certificates	C-TICK, CB, CCC, CE, China RoHS, Federal Communications Commission (FCC), ICES, PSE, RCM, RoHS, cTUVus, UKCA, VCCI, WEEE
Height (without stand)	350.4 mm
Depth (without stand)	53.6 mm
Width (without stand)	537.8 mm
Power consumption (max)	50 W
Quick start guide	Yes
HDMI	Yes
Energy efficiency scale	A to G
Touchscreen	No
Certificates
Certification	CE, UKCA, CB, C-Tick, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 9, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC
Logistics data
Harmonized System (HS) code	85285210
